14.4 kWh storage + 15 kW inverter (Foxess).
The kit consists of a FoxESS H3-Pro-15.0 hybrid inverter with FoxESS 2.88 kWh battery modules (5 units) and a 2.88 kWh battery with integrated BMS (1 unit).
This kit ensures reliable energy storage and efficient operation of the solar power plant.
The system’s power allows you to optimise your electricity consumption, reduce costs and provide back-up power in the event of a power outage.
The modular design provides flexibility for expanding capacity, while the advanced BMS (Battery Management System) management ensures safety and longevity. It is the ideal solution for homes or businesses looking to use renewable energy efficiently.
| Rinkinio komponentai | Inverter (10 kW) + 4 pcs. battery modules (2,88 kWh) + battery module (2,88 kWh) with controller |
|---|---|
| Bendra kaupimo talpa | 14.4 kWh (5 × 2.88 kWh) |
| Maks. atiduodama galia | 10 kW |
| Energijos šaltiniai | Electricity network, Solar power plant |
| Back-up funkcija (veikia dingus elektrai) | Yes |
| Montavimo būdas | Built on the ground, Wall-mounted |
| Valdymas programėle | Yes |
| Warranty | 10 m. |
| Manufacturer | FoxESS |
|---|---|
| Model | H3-PRO-15.0 |
| Battery type | LiFePO₄ (Lithium Iron Phosphate) |
| Voltage | 160 V - 800 V |
| Max. power output | 15 kW |
| Phases | 3 phases |
| Current | 24 A |
| Voltage | 230 V / 400 V |
| Back-up function | Available at |
| Class of protection | IP65 |
| Dimensions | 563 × 692 × 278 mm |
| Weight | 43 kg |
| Installation method | Wall-mounted |
| Operating temperature | -25° to 60°C |
| Communications | Wi-Fi, LAN, RS485, CAN, Modbus |
| App control | Yes |
| App for management | FoxESS Cloud |
| Country of manufacture | China |
| Warranty | 10 m. |
